Smartgen HAT700 User Manual

HAT700 SERIES ATS CONTROLLER USER MANUAL
HAT700 Series ATS Controller 2018-12-13 Version 1.5 Page 26 of 51
No.
Item
Range
Default
Description
Active Type
1:Normally close
14
Combined 1 Or Out 1
Contents Setting
(0-92)
23
S1 Normal
15
Combined 1 Or Out 2
Active Type
(0-1)
0
0:Normally open;
1:Normally close
16
Combined 1 Or Out 2
Contents Setting
(0-92)
25
S2 Normal
17
Combined 1 And Out
Active Type
(0-1)
1
0:Normally open;
1:Normally close
18
Combined 1 And Out
Contents Setting
(0-92)
0
Not Used
19
Combined 2 Or Out 1
Active Type
(0-1)
0
0:Normally open;
1:Normally close
20
Combined 2 Or Out 1
Contents Setting
(0-92)
0
Not Used
21
Combined 2 Or Out 2
Active Type
(0-1)
0
0:Normally open;
1:Normally close
22
Combined 2 Or Out 2
Contents Setting
(0-92)
0
Not Used
23
Combined 2 And Out
Active Type
(0-1)
0
0:Normally open;
1:Normally close
24
Combined 2 And Out
Contents Setting
(0-92)
0
Not Used
25
Combined 3 Or Out 1
Active Type
(0-1)
0
0:Normally open;
1:Normally close
26
Combined 3 Or Out 1
Contents Setting
(0-92)
0
Not Used
27
Combined 3 Or Out 2
Active Type
(0-1)
0
0:Normally open;
1:Normally close
28
Combined 3 Or Out 2
Contents Setting
(0-92)
0
Not Used
29
Combined 3 And Out
Active Type
(0-1)
0
0:Normally open;
1:Normally close
30
Combined 3 And Out
Contents Setting
(0-92)
0
Not Used
31
Combined 4 Or Out 1
Active Type
(0-1)
0
0:Normally open;
1:Normally close
32
Combined 4 Or Out 1
Contents Setting
(0-92)
0
Not Used
33
Combined 4 Or Out 2
Active Type
(0-1)
0
0:Normally open;
1:Normally close
34
Combined 4 Or Out 2
Contents Setting
(0-92)
0
Not Used
35
Combined 4 And Out
Active Type
(0-1)
0
0:Normally open;
1:Normally close
36
Combined 4 And Out
(0-92)
0
Not Used
