HAT700 SERIES ATS CONTROLLER USER MANUAL
HAT700 Series ATS Controller 2018-12-13 Version 1.5 Page 27 of 51
No.
Item
Range
Default
Description
Contents Setting
37
Combined 5 Or Out 1
Active Type
(0-1)
0
0:Normally open;
1:Normally close
38
Combined 5 Or Out 1
Contents Setting
(0-92)
0
Not Used
39
Combined 5 Or Out 2
Active Type
(0-1)
0
0:Normally open;
1:Normally close
40
Combined 5 Or Out 2
Contents Setting
(0-92)
0
Not Used
41
Combined 5 And Out
Active Type
(0-1)
0
0:Normally open;
1:Normally close
42
Combined 5 And Out
Contents Setting
(0-92)
0
Not Used
43
Combined 6 Or Out 1
Active Type
(0-1)
0
0:Normally open;
1:Normally close
44
Combined 6 Or Out 1
Contents Setting
(0-92)
0
Not Used
45
Combined 6 Or Out 2
Active Type
(0-1)
0
0:Normally open;
1:Normally close
46
Combined 6 Or Out 2
Contents Setting
(0-92)
0
Not Used
47
Combined 6 And Out
Active Type
(0-1)
0
0:Normally open;
1:Normally close
48
Combined 6 And Out
Contents Setting
(0-92)
0
Not Used
Module Setting
1
Power On Mode
(0-2)
0
0: Previous Mode (Keep the working mode
last time running)
1: Manual
2: Auto
2
Module Address
(1-254)
1
RS485 communication address
3
Language
(0-2)
0
0: Chinese
1: English
2: OthersLanguage can be set via PC
software
4
Password
(00000-65535)
01234
For entering parameters setting.
5
Baud Rate
(0-3)
2
0:2400
1:4800
2:9600
3:19200
6
Stop Bit
(1-2)
2
2 stop bits or 1 stop bit can be set.
7
Date and Time
