Smartgen HGM6100K Series User Manual

HGM6100K Series Automatic Generator Module
HGM6100K Series Automatic Generator Module ISSUE 2011-04-12 Version 1.6 Page 10 of 31
No.
Type
Description
2
Gens Over
Current
When controller detected the current of genset is over
than threshold and over current delay set as 0,
controller will send warning alarm signal and it will be
displayed in LCD
3
Failed To Stop
When generator not stops after the “stop relay” is over,
controller will send warning alarm signal and it will be
displayed in LCD
4
Low oil level
When controller detected the oil level of genset is lower
than threshold or low oil level warn input is active,
controller will send warning alarm signal and it will be
displayed in LCD
5
Charge Alt Fail
When controller detected the voltage of genset charger
is lower than threshold, controller will send warning
alarm signal and it will be displayed in LCD
6
Battery Low
Voltage
When controller detected the voltage of genset battery
is lower than threshold, controller will send warning
alarm signal and it will be displayed in LCD
7
Battery High
Voltage
When controller detected the voltage of genset battery
is higher than threshold, controller will send warning
alarm signal and it will be displayed in LCD
8
Low water level
When controller detected the warning of low water level
input is active, controller will send warning alarm signal
and it will be displayed in LCD
5.2 SHUTDOWN ALARM
When controller detected shutdown alarm, it will send signal to break off and to stop.
The alarms are displayed in LCD.
Stop alarms as following,
No.
Type
Description
1
Emergency Stop
When controller detected emergency stop signal, it will
send a stop alarm signal and it will be displayed in LCD
2
High Temp
alarm
When controller detected the temperature of
water/cylinder is higher than set, it will send a stop
alarm signal and it will be displayed in LCD
3
Lower OP
alarm
When controller detected oil pressure is lower than set
for alarming, it will send a stop alarm signal and it will
be displayed in LCD
4
Over speed
alarm
When controller detected genset speed is over than set
for alarming, it will send a stop alarm signal and it will
be displayed in LCD
5
Under speed
When controller detected genset speed is under than
