Smartgen HGM6100K Series User Manual

HGM6100K Series Automatic Generator Module
HGM6100K Series Automatic Generator Module ISSUE 2011-04-12 Version 1.6 Page 14 of 31
7 PARAMETER RANGE AND DEFINE
All parameters of HGM6100K series are as following:
7.1 PARAMETERS TABLE (TABLE 1)
Num
Parameter
Range
Default
Description
1
Mains volt
normal delay
(0-3600)s
10
Mains transient delay,
suited for ATS (automatic
transfer switch).
2
Mains volt
abnormal delay
(0-3600)s
5
3
Mains under volt
(30-360)V
184
When mains voltage is
under than the point,
mains under voltage are
active. When the point is
zero, mains under voltage
are disabled.
4
Mains over volt
(30-360)V
276
When mains voltage is
over than the point, mains
over voltage are active.
When the point is 360V,
mains over voltage are
disabled.
5
Transfer Switch
interval
(0-99.9)s
1.0
It‟s the delay from mains is
opened to generator
closing or from generator
is opened to mains
closing.
6
Start delay
(0-3600)s
1
It‟s the delay from remote
start signal is active or
mains is failure, to start
generator.
7
Stop delay
(0-3600)s
1
It‟s the delay from remote
start signal is inactive or
mains is normal, to stop
generator.
