Smartgen HGM6100K Series User Manual

HGM6100K Series Automatic Generator Module
HGM6100K Series Automatic Generator Module ISSUE 2011-04-12 Version 1.6 Page 15 of 31
Num
Parameter
Range
Default
Description
8
Number of crank
(1-10)times
3
When engine start no
success, most of cranking
numbers. When reach
setting crank numbers,
controller send out start fail
signal.
9
Preheat time
(0-300)s
0
10
Crank time
(3-60)s
8
The starter adds the time
of the electricity each time.
11
Crank rest time
(3-60)s
10
12
Safe run time
(1-60)s
10
13
Start idle time
(0-3600)s
0
14
Warming up time
(0-3600)s
10
15
Cooling time
(3-3600)s
10
16
Stop idle time
(0-3600)s
0
17
ETS solenoid
hold
(0-120)s
20
It‟s the delay for energizing
to stop.
18
Fail to stop delay
(0-120)s
0
19
ATS close time
(0-10)s
5.0
Mains or Generator switch
closing pulse width, when
it is zero, output is
continuous.
20
Flywheel teeth
(10-300)
118
21
Gens abnormal
delay
(0-20.0)s
10.0
22
Gens over volt
(30-360)V
264
When generator voltage is
over than the point,
generator over voltage is
active. When the point is
360V, generator over
voltage is disabled.
23
Gens under volt
(30-360)V
196
When generator voltage is
under than the point,
generator under voltage is
active. When the point is
30V, generator under
voltage is disabled.
24
Under speed
(0-6000)RPM
1200
When the engine speed is
under than the point and
hold great than 10
seconds, generator under
speed is active.
