HGM6100K Series Automatic Generator Module
HGM6100K Series Automatic Generator Module ISSUE 2011-04-12 Version 1.6 Page 25 of 31
■ Set language
User may set display interface language as Chinese, English, Spanish and
Russian.
Note: Press the key will exit setting interface at any time.
9 SENSOR SELECTION
1． When the choice sensor, the sensor to standard curve will call. If factory set
temperature sensor for SGH (120 degrees resistance-type), sensor curve for
SGH (120 degrees resistance-type), 120 degrees Celsius (elected SGD type),
resistively curve for temperature sensor SGD curve.
2． If use standard sensor with the curve, can differ option "item sensor curve
input", after adjusting adjustment can be determined according to save.
3． When the input sensor curve, X (resistance) must be in accordance with the
order of big from small, otherwise will enter errors.
4． When the sensor is choosing "nothing", the sensor curves no affection, LCD
display temperature or pressure for---.
5． If there is no pressure sensor, only low pressure alarm switch, it must be
alarm settings for pressure sensor "nothing", otherwise may appear oil
pressure low alarm shutdown.
6． Can set up several point of forehand or several point of backmost ordinate the
same. The following picture:
