HGM6100K Series Automatic Generator Module
HGM6100K Series Automatic Generator Module ISSUE 2011-04-12 Version 1.6 Page 21 of 31
Num
Content
Description
14
Reserved
15
Reserved
16
Reserved
17
Reserved
7.3 PROGRAMMABLE DIGIT INPUT 1-5 TABLE (ALL IS VALID
WHEN CONNECT GRAND (B-) (TABLE 3)
Num
Content
Description
0
Not used
1
High Temp. alarm input
After the end of the delay in the safe
operation, if the signal is active, generator will
immediately alarm shutdown.
2
Low OP alarm input
3
Auxiliary warn input
Auxiliary warn alarm digital input.
4
Auxiliary shutdown
alarm input
When power on, if active, generator will stop
immediately.
5
Stop after cooled
During engine running, if the engine occur
high temperature shutdown, when the input is
active, the engine will first initiate cooling
delay and then stop, else will stop
immediately.
6
Gens closed state
input
The input state of generator closed.
7
Mains closed state
input
The input state of Mains closed.
8
Higher temp. stop
prohibit
When it is active, prohibit stop when higher
temperature. Details see Note1.
9
Oil pressure lower stop
prohibit
When it is active, prohibit stop when oil
pressure lower. Details see Note2.
10
Remote start input
11
Low Fuel Level warn
12
Low coolant level warn
13
Low Fuel Level
shutdown
14
Low coolant level
shutdown
15
Automatic start Inhibit
This input is used to provide an over-ride
function to prevent the 6100K from starting the
generator in the event of a remote start/ mains
out of limits condition occurring. If this input is
