HGM6100K Series Automatic Generator Module
HGM6100K Series Automatic Generator Module ISSUE 2011-04-12 Version 1.6 Page 20 of 31
The designated programmable output relay
will energize when a stop signal has been
activated. The output will remain energized for
pre-set timer once the engine has come to a
complete stop, then de-energizes.
The designated programmable output relay
will energize when the idle delay is not zero.
The output contact would typically be
connected to the “idle/run” input control of an
electronic governor.
The designated programmable output relay
will energize during the preheat delay timer
period and also energize until the engine
receive a crank success signal. The preheat
output is typically used for an engine starting
aid such as glow plugs.
Switch generator breaker on.
Switch mains breaker on.(HGM6120KC)
Switch breaker off. The output delay is 3
seconds.
In the process of warm-up when he entered
the suction, suck time for high-speed warm-up
delay time. Raise speed auxiliary input
effective disconnect.
Enter into stop idling process or to ETS
solenoid stop (when alarm stop) sucked, and
suck time to stop idling delay time. Drop
speed when the auxiliary active disconnect.
Outputting when genset in normal running
and disconnected after speed is lower than
start successful speed value.
When the fuel level lower than the set
threshold to open the fuel pump or input a low
oil level warning enter active pull; when the
fuel level over than that set off the fuel pump
and the input threshold of the low oil level
warning off when input is inactive open.
Outputting when genset enters into "Warming
Up" and disconnected after "Cooling Down" is
over.
The controller work in automatic mode.
