Smartgen HGM6100K Series User Manual

HGM6100K Series Automatic Generator Module
HGM6100K Series Automatic Generator Module ISSUE 2011-04-12 Version 1.6 Page 19 of 31
Num
Parameter
Range
Default
Description
65
Freq disconnect
(10-30)Hz
14
When generator frequency
is over than this point,
starter will disconnect.
66
OP disconnect
(0-400)kPa
200
When engine oil pressure
is over than this point,
starter will disconnect.
67
High temp.
prohibit select
(0-1)
0
Default, when temperature
is higher, alarm to stop.
Details see Note1.
68
Low OP prohibit
select
(0-1)
0
Default, when oil pressure
is lower, alarm to stop.
Details see Note2.
69
Single/3 phases
input select
0
3phase-4wire
1
2phase-3wire
2
1phase-2wire
0
3phase-4wire
70
Select temp.
sensor
(0-9)
08
SGX
71
Select press
sensor
(0-9)
08
SGX
72
Select liquid
level sensor
(0-5)
03
SGD
Note 1, if set as higher temperature to prohibit stop, or set programmable port as
higher temperature prohibits stop and this port is active, when temperature value
is higher than set of higher temperature value or higher temperature alarm input is
active, controller send warning signal of higher temperature only and not stop.
Note 2, if set as lower oil pressure to prohibit stop, or set programmable port as
lower oil pressure prohibits stop and this port is active, when lower oil pressure
value is lower than set of lower oil pressure value or lower oil pressure alarm input
is active, controller send warning signal of higher temperature only and not stop.
7.2 PROGRAMMABLE OUTPUT 1-4 TABLE (TABLE 2)
Num
Content
Description
0
Not used
Output is no use when select this
1
Common alarm
The designated programmable output relay
will energize when any warning or shutdown
fault circuit has been activated.
