Smartgen HGM6100K Series User Manual

HGM6100K Series Automatic Generator Module
HGM6100K Series Automatic Generator Module ISSUE 2011-04-12 Version 1.6 Page 18 of 31
Num
Parameter
Range
Default
Description
40
Fuel pump off
threshold
(0-100)%
80
When the fuel level higher
than the set value and for
10 seconds, the output fuel
pump off signal.
41
Digit Output1 set
(0-17)
2
Energized to stop
42
Digit Output 2
set
(0-17)
3
Idle control
43
Digit Output 3
set
(0-17)
5
Close gens
44
Digit Output 4
set
(0-17)
6
Close mains
45
Aux. input1
(0-15)
1
High Temperature input
46
Aux. input1 valid
(0-1)
0
Factory default is: closed
47
Aux. input1
delay
(0-20.0)s
2.0
48
Aux. input2
(0-15)
2
Low Oil Pressure input
49
Aux. input2 valid
(0-1)
0
Factory default is: closed
50
Aux. input2
delay
(0-20.0)s
2.0
51
Aux. input3
(0-15)
10
Remote start input
52
Aux. input3 valid
(0-1)
0
Factory default is: closed
53
Aux. input3
delay
(0-20.0)s
2.0
54
Aux. input4
(0-15)
11
Low fuel level warn
55
Aux. input4 valid
(0-1)
0
Factory default is: closed
56
Aux. input4
delay
(0-20.0)s
2.0
57
Aux. input5
(0-15)
12
Low coolant level warn
58
Aux. input5 valid
(0-1)
0
Factory default is: closed
59
Aux. input5
delay
(0-20.0)s
2.0
60
Module power
on
(0-2)
0
0: Stop mode
1: Manual mode
2: Auto mode
61
Module address
(1-254)
1
62
Passwords set
(0-9999)
1234
63
Crank success
condition select
(0-5)
2
Setting item is given in
Table 5.
64
Speed
disconnect
(0-3000)RPM
360
When engine speed is
over than this point, starter
will disconnect.
