Smartgen HGM6100K Series User Manual

HGM6100K Series Automatic Generator Module
HGM6100K Series Automatic Generator Module ISSUE 2011-04-12 Version 1.6 Page 17 of 31
Num
Parameter
Range
Default
Description
31
Lose speed
delay
(0-20.0)s
5.0
When speed is zero and
remain for the delay, send
out shutdown alarm. When
the delay is zero, send out
warning alarm.
32
Charge fail volt
(0-30)V
6.0
During generator is
running, when charge
alternator WL/D+ voltage
is under than this point and
remain for 5 seconds,
generator will warning
alarm.
33
Battery over volt
(12-40)V
33.0
When generator battery
voltage is over than the
point and hold for 20
seconds, battery over
voltage signal is active. It‟s
a warning alarm.
34
Battery under
volt
(4-30)V
8.0
When generator battery
voltage is under than the
point and hold for 20
seconds, battery under
voltage signal is active. It‟s
a warning alarm.
35
CT rate
(5-6000)/5
500
Current transformer rate
36
Full load current
(5-6000)A
500
Mains or generator set
maximum rated current.
37
Over current
percentage
(50-130)%
120
When the load current is
over than the point, the
over current delay is
initiated.
38
Over current
delay
(0-3600)s
1296
When load current is over
than the point and hold
great than the timer, send
out over current signal.
When the delay is zero,
over current is disabled.
39
Open Fuel
Pump threshold
(0-100)%
25
When the fuel level lower
than the set value and for
10 seconds, the output
signal to open fuel pump.
