HGM6100K Series Automatic Generator Module ISSUE 2011-04-12 Version 1.6 Page 13 of 31
Pin
Function
Dim
Description
input
15
Magnetic pickup +ve
Connect to Magnetic Pickup device.
16
Magnetic pickup -ve
17
Temp. sensor input
Connecting water/cylinder
temperature resistance type
sensor.
Reference
table 4
18
Oil pressure input
Connect to oil pressure sensor.
19
Liquid level input
Connect to liquid Level sensor.
20
Auxiliary input 1
1.0mm
Switch to -ve
Reference
table 3
21
Auxiliary input 2
1.0mm
Switch to -ve
22
Auxiliary input 3
1.0mm
Switch to -ve
23
CT Secondary for A
1.5mm
Connect to secondary of A
monitoring CT
24
CT Secondary for B
1.5mm
Connect to secondary of B monitoring
CT
25
CT Secondary for C
1.5mm
Connect to secondary of C monitoring
CT
26
CT secondary common
1.5mm
Connect to secondary of all monitoring
CT‟s
27
Generator A voltage
monitoring
1.0mm
Connect to Generator A output
(Recommend 2A fuse)
28
Generator B voltage
monitoring
1.0mm
Connect to Generator B output
(Recommend 2A fuse)
29
Generator C voltage
monitoring
1.0mm
Connect to Generator C output
(Recommend 2A fuse)
30
Generator Neutral input
1.0mm
Connect to generator neutral
terminal (AC)
31
Mains A voltage
monitoring
1.0mm
Connect to mains A output
(Recommend 2A fuse)
32
Mains B voltage
monitoring
1.0mm
Connect to mains B output
(Recommend 2A fuse)
33
Mains C voltage
monitoring
1.0mm
Connect to mains C output
(Recommend 2A fuse)
34
Mains Neutral input
1.0mm
Connect to mains neutral terminal
35
RS485 port common
0.5mm
Use only 120Ω RS485 approved cable.
36
RS485 port A(-)
0.5mm
37
RS485 port B(+)
0.5mm
38
Auxiliary input 4
1.0mm
Switch to -ve
Reference
table 3
39
Auxiliary input 5
1.0mm
Switch to -ve
40
Common port
1.0mm
Auxiliary input common port
Note: LINK interface in back is as a parameter programming interface, by PC to
programmable controller via SG72 adapter.
