MGC120 Petrol Genset Controller Version 1.2 2019-02-22 Page 11 of 20
No.
Function
Cable Size
Note
18
Generator Phase Voltage
(L-N) Monitoring Input
1.0 mm
2
Connect with generator voltage output port (2A fuse is
recommended)
19
1.0 mm
2
Note: the COM (red cable) for stepper motor shall be connected to battary positive.
7 DEFINITION AND RANGE OF PARAMETERS
7.1 PARAMETER SETTING CONTENTS AND RANGE
Table 6 Controller Configuration Parameters
No.
Items
Parameter Range
Default
Description
P00
Mains Normal Delay
(0-3600)s
10
Time duration for Mains voltage from
abnormal to normal or from normal to
abnormal is used for ATS to switch.
P01
Mains Abnormal
Delay
(0-3600)s
5
P02
Mians Under Volt
Value
(30-360)V
184
If the voltage sample is lower than it, under
voltage of Mains is considered; When it is
set 30V, under voltage signal shall not be
detected.
P03
Mains Over Volt
Value
(30-360)V
276
If the voltage sample is higher than it, over
voltage of Mains is considered; When it is
set 360V, overvoltage signal shall not be
detected.
P04
Transfer Delay
(0-99.9)s
1.0
It is the time interval for transferring switch
from mains open to generator close or from
generator open to mains close.
P05
Mains Options
(0-1)
0
0：AMF(mains abnormal start enabled in
auto mode)
1： Display Only (only monitoring mains
voltage)
P06
Start Delay
(0-3600)s
1
Time duration from remote start signal is
active to engine startup.
P07
Stop Delay
(0-3600)s
1
Time duration from remote start signal is
deactivated to engine stop.
P08
Start Attempts
(1-10)
3
It is maximum start attempts when starter
fails to start. When it reaches set attempts
controller shall send out start failure signal.
P09
Cranking Time
(3-60)s
8
Time for starter to be energized every time.
P10
Crank Rest Time
(3-60)s
10
The waiting time before second power up
when engine start fails.
P11
Safety On Delay
(1-60)
10
Alarms for low oil pressure, under frequency
and under voltage are deactivated.
P12
Warming Up Time
(0-3600)s
10
Warming-up time before breaker close after
high speed running for genset.
P13
Cooling Time
(3-3600)s
10
Radiating time before genset stop after
genset is unloaded.
