MGC120 Petrol Genset Controller User Manual
MGC120 Petrol Genset Controller Version 1.2 2019-02-22 Page 5 of 20
3 SPECIFICATION
Table 2 Technical Parameters
Items
Contents
Working Voltage
Suitable for DC12V power supply system;
Overall Consumption
Regular working:<2W(stepper motor is excluded)
Standby mode:<0.5W
AC Volt Input:
Mains Single Phase
Generator Single Phase
AC 30V - AC 360V (ph-N)
AC 30V - AC 360V (ph-N)
Alternator Frequency
50Hz/60Hz
Starter Relay Output
10A DC30V DC B+ supply output
Fuel Relay Output
10A DC30V DC B+ supply output
Ignition Relay Output
10A DC30V DC B- supply output
Flexible Transistor Output
1A connecting with DC B+ supply output
Stepper Motor Recommended
24BYJ48-12V(stepper angle 5.625° reduction ratio 16:1)
Overall Dimensions
95mm x 86mm x 46.5mm
Panel Cutout
78mm x 66mm
Working Condition
Temperature:(-25~+70)°C Humidity:(20~93)%RH
Storage Condition
Temperature:(-25~+70)°C
Protection Level
Front panel IP55
Insulation
Apply AC2.2kV voltage between high voltage terminal and low voltage
terminal and the leakage current is not more than 3mA within 1min.
Weight
0.15kg
