Smartgen MGC120

MGC120 Petrol Genset Controller User Manual
MGC120 Petrol Genset Controller Version 1.2 2019-02-22 Page 14 of 20
No.
Items
Range
Default
Description
7
Fuel Output
(0-1)
0
0： Fuel Output
1： ETS Output
8
Digital Input 1
(0-6)
1
Configure the function of controller terminal 6;
Default: remote start input, for details please
see Table 9.
9
Digital Input 2
(0-6)
2
Configure the function of controller terminal 7;
Default: low oil pressure input, for details please
see Table 9.
Note: when parameter settings are condcuted via PC software, it is needless to entry the password if default
password (0318) has not been changed; if it has been changed and it is the first time to conduct parameter settings via PC
software, it is needed to entry the module password on the password screen.
7.2 PROGRAMMABLE OUTPUT DEFINABLE CONTENTS
Table 8 Definable Contents For Programmable Outputs
No.
Items
Function Description
0
Not Used
When this is chosen, output port won’t output.
1
Common Alarm
When stop alarm is initiated, this alarm will self-lock untill alarm reset.
2
ETS Control
It is used for some gensets with stop electromagnet. Pull-in occurs when
“stop idle speed” ends. Open occurs when “ETS Delay” ends.
3
Idle Speed Control
It is used for engines with idling speed. Pull-in occurs when the engine
starts. Open occurs when it enters “Warming-up”. Pull-in occurs in the
stopping process of idling speed and open occurs when the genset stops
completely.
4
Preheating Control
Close before start, open before energization.
5
Gen Close Output
Generator close outputs when generator is normally running.
6
Mains Close Output
Mains close outputs after mains normal delay ends.
7
Air Flap Choke
It outputs when engine starts, and it disconnects when engine has started.
8
Reserved
9
Reserved
7.3 PROGRAMMABLE INPUT DEGINED CONTENTS
No.
Items
Remark
0
Not Used
1
Remote Start Input
In auto mode, genset starts up if this signal is active.
2
Low Oil Pressure Input
After safety on delay is finished, generator shutdown alarm occurs
immidiately if this signal is active.
3
Gen Close Input
In manual mode, and under the condition that genset is normally
running, generator close outputs when this sigal is active, otherwise,
mains close outputs.
4
Reserved
5
Reserved
6
Reserved
