MGC120 Petrol Genset Controller User Manual
MGC120 Petrol Genset Controller Version 1.2 2019-02-22 Page 13 of 20
No.
Items
Parameter Range
Default
Description
shall open. If it is between the blocking value
and opening value, the air flap opens 1/2.
P28
Aux. Output 1
(0-9)
5
Default function: generator close output. For
details please see Table 8.
P29
Aux. Output 2
(0-9)
6
Default function: mains close output. For
details please see Table 8.
P30
Power On Mode
Selection
(1-2)
1
1：Manual Mode
2：Auto Mode
P31
Module Address
(1-254)
1
Communication address with PC software.
P32
Password
(0-9999)
0318
Controller password.
P33
Crank
Disconnection
Conditions
(0-2)
2
0：Generator frequency
1：Engine Speed
2： Generator frequency + engine speed
It is used for judging crank disconnection
condition.
P34
Disconnection
Engine Speed
(0-3000)r/min
840
When engine speed is over this value, it is
considered that start is successful and
starter will be disconnected.
P35
Disconnection Gen.
Frequency
(0-30.0)Hz
14.0
In the starting process when generator
frequency exceeds this value, it is
considered that start is successful and
starter will be disconnected.
P36
Temp Sensor Types
(0-4)
0
0：Not used
1：PT100
2：NTC-1K
3：Reserved
4：Users-defined resistor curves
Table 7 Configurable Parameters Only For HMI
No.
Items
Range
Default
Description
1
Pre-heat Delay
(0-300)s
0
Time for heater plug to be energized in advance
before starter is powered on.
2
Start Idle Time
(0-3600)s
0
Idling speed running time when genset is
starting.
3
Stop Idle Time
(0-3600)s
0
Idling speed running time when genset is
stopping.
4
Stepper Motor
Frequency
(100-500)Hz
250
rotation steps for the motor per second
5
Stepper Motor
Steps
(0-2000)
128
Step numbers needed for motor rotating 90°;
calculation formula: 360 * reduction ratio/( step
angle*4)
for example：128 = 360 * 16 / (5.625*2*4)
6
Ignition Output
(0-1)
0
0：Output when stop
1：Output when start
