Advanced Settings Detail
Index Description Range Default Note
000 TSC Firmware Version N/A N/A
001 Ceiling Controller Hardware Version N/A N/A
002 Ceiling Controller Firmware Version N/A N/A
003 Ceiling Controller Macro Version N/A N/A
004 Maximum Roof Temperature 20°C - 50°C 30°C *1
005 Minimum Roof Temperature 0°C - 20°C 5°C *1
006 Set Temperature Threshold 0°C - 5°C 1°C
007 Set Temperature Differential Threshold 0°C - 20°C 5°C
008 Heat Transfer High Threshold 0°C - 15°C 5°C
009 Heat Transfer Medium Threshold 0°C - 15°C 2°C
010 Filter Used Percentage / Reset N/A N/A
011 Ceiling Temperature Calibration -5°C - 5°C 0°C *2
012 Room Temperature Calibration -5°C - 5°C 0°C *2
013 Maximum Backlight Brightness 0-100% 80%
014 Minimum Backlight Brightness 0-100% 10%
015 Boost Timer 0 min – 60 min 20 min
016 Filter Reset 0 - 100 0 *3
017 Reserved N/A N/A
Notes:
*1. If RECYCLE
mode is enabled and the incoming air temperature sensor
reading goes above the maximum temperature setting or goes below the
minimum temperature setting, then recycle mode will turn on.
*2. If your incoming air or room temperature readings are inaccurate, use these
settings to calibrate them.
*3. Change setting value to 10 and press SELECT to reset the filter timer.
