C-1
A
PPENDIX
C
S
PECIFICATIONS
Physical Characteristics
Ports
Four 10/100Mbps RJ-45 ports
One ADSL RJ-11 port
Two external dipole antennas
ADSL Features
Supports DMT line modulation
Supports Annex A Full-Rate ADSL: up to 8 Mbps downstream, up to
1 Mbps upstream (G.992.1 &T1.413, Issue 2)
Supports G.Lite ADSL: up to 1.5 Mbps downstream, up to 512 Kbps
upstream
Dying GASP support
ATM Features
RFC1483 Encapsulation (IP, Bridging and encapsulated routing)
PPP over ATM (LLC &VC multiplexing) (RFC2364)
Classical IP (RFC1577)
Traffic shaping (UBR, CBR)
OAM F4/F5 support
PPP over Ethernet Client
Management Features
Firmware upgrade via web based management
web based management (configuration)
Power Indicators
Event and History logging
Network Ping
