SMC Networks EX600-DX Series User Manual

-18-
No.EX##-OMN0036
•EX600-DX C

No. Description Function
1 Status display LED Displays the status of the unit.
2 Connector (Input) Connector for input device.
3 Marker groove Groove to mount a marker.
4 Joint bracket Bracket for joining to adjacent units.
5 Unit connector (Plug) Transmits signals and power supplies to adjacent units.
•EX600-DX D
No. Description Function
1 Status display LED Displays the status of the unit.
2 Connector (Input) Connector for input device.
3 Marker groove Groove to mount a marker.
4 Joint bracket Bracket for joining to adjacent units.
5 Unit connector (Plug) Transmits signals and power supplies to adjacent units.
