101
110
86
38
36.2
18.1
85
1.2
4.5
110
86
38
36.2
85
(11.5)
24.235
q Jog operation is a function that is provided mainly for checking the operation of the machine when adjusting, inspecting,
or performing maintenance on it.
While a jog operation is taking place, the alarm related to operation will not be detected. For this reason, it is not recommended to
use this function during automatic operation of the machine.
w If the moving part of the electric actuator is caused to collide with an object during a jog operation, the electric actuator
is likely to break down.
Before using the actuator, carefully check that it will not collide with any objects.
Caution
Dimensions
Screw mounting (LEC1--XB182)
DIN rail mounting (
LEC1D--XB182)
With Input Signals to Perform Jog Operations
Step Motor Controller
LECP1-XB182
133.2 (When removing DIN rail)
127.3 (When locking DIN rail)
CN4 I/O connector
CN2 motor connector
Ø 4.5
For body mounting
4.5
For body mounting
CN3 encoder
connector
CN1 power supply
connector
10
To Next Page
