SMC Networks LECP1 Series Manual

Specifi cations
Basic Specifi cations
Note 4) Applicable to non-magnetizing lock.
Decimal display
Hexadecimal display
10
A
11
b
12
c
13
d
14
E
15
F
Note 1) Do not use the power supply of “inrush current prevention type” for the controller input power supply. When conformity to UL is required, the
electric actuator and controller should be used with a UL1310 Class 2 power supply.
Note 2) The power consumption changes depending on the actuator model. Refer to the each actuator’s operation manual etc. for details.
Note 3) “10” to “15” in decimal number are displayed as follows in the 7-segment LED.
Item
LECP1
Compatible motor
Step motor (Servo/24 VDC)
Power supply
Note 1)
Power supply voltage: 24 VDC ±10 %
Note 2)
[Including the motor drive power, control power supply, stop, lock release]
Parallel input
6 inputs (Photo-coupler isolation)
Parallel output
6 outputs (Photo-coupler isolation)
Stop points
14 points (Position number 1 to 14(E))
Compatible encoder
Incremental A/B phase (800 pulse/rotation)
Memory
EEPROM
LED indicator
LED (Green/Red) one of each
7-segment LED display
Note 3)
1 digit, 7-segment display (Red) Figures are expressed in hexadecimal (“10” to “15” in decimal number are expressed as “A” to “F”)
Lock control
Forced-lock release terminal
Note 4)
Cable length [m]
I/O cable: 5 or less, Actuator cable: 20 or less
Cooling system
Natural air cooling
Operating temperature range [ ° C]
0 to 40 (No freezing)
Operating humidity range [%RH]
90 or less (No condensation)
Storage temperature range [ ° C]
−10 to 60 (No freezing)
Storage humidity range [%RH]
90 or less (No condensation)
Insulation resistance [MΩ]
Between the housing and SG terminal: 50 (500 VDC)
Weight [g]
130 (Screw mounting), 150 (DIN rail mounting)
LECP1 Series
How to Order
C 1LE P
1N
1
1
P
Controller
Compatible motor
Controller type
Number of step data (Points)
Parallel I/O type
I/O cable length [m]
I/O cable length [m]
Actuator part number
Actuator type
(Except cable specifi cations and actuator options)
Example: Enter “LEFS16A-400” for the
LEFS16A-400B-R11N1.
∗ When controller equipped type is selected
when ordering the LE series, you do not
need to order this controller.
Option
Note) DIN rail is not included.
Order it separately.
Refer to “How to Order” in the actuator catalogue and indicate the model.
For compatible actuators, refer to the table below.
Example: LEFS16B-100-R31N1
—
Screw mounting
D
Note)
DIN rail mounting
—
Without cable
1
1.5
3
3
5
5
—
Without cable
1
1.5
3
3
5
5
N
NPN
P
PNP
1
14 (Programless)
P
Step motor (Servo/24 VDC)
—
Without controller
1N
With programless controller (NPN)
1P
With programless controller (PNP)
LEFS16A-400
LEFS16B-100-R3
[CE-compliant products]
EMC compliance was tested by combining the electric actuator LE series and the controller LEC series.
The EMC depends on the confi guration of the customer’s control panel and the relationship with other electrical
equipment and wiring. Therefore, conformity to the EMC directive cannot be certified for SMC components
incorporated into the customer’s equipment under actual operating conditions. As a result, it is necessary for the
customer to verify conformity to the EMC directive for the machinery and equipment as a whole.
[UL-compliant products]
When conformity to UL is required, the electric actuator and controller should be used with a UL1310 Class 2 power supply.
Caution
The controller is sold as
single unit after the
compatible actuator is set.
Confi rm that the combination of the
controller and the actuator is correct.
Part number for actuator and controller set.
∗ Refer to the operation manual for using
the products. Please download it via our
website, http://www.smc.eu
Compatible actuators
LEF LEL LEY LES LEPLER LEH
Controller
Controller with actuator
LEM
1
