LECP1 Series
Dimensions
Screw mounting (LEC1-)
DIN rail mounting (LEC1D-)
DIN rail
AXT100-DR-
DIN rail mounting adapter
LEC-1-D0 (with 2 mounting screws)
This should be used when the DIN rail mounting adapter is mounted onto the screw mounting type controller afterwards.
∗ For , enter a number from the “No.” line in the
table below.
Refer to the dimensions above for the mounting
dimensions.
L Dimension [mm]
No.123456789101112131415161718192021
L
23 35.5 48 60.5 73 85.5 98 110.5 123 135.5 148 160.5 173 185.5 198 210.5 223 235.5 248 260.5 273
No. 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40
L
285.5 298 310.5 323 335.5 348 360.5 373 385.5 398 410.5 423 435.5 448 460.5 473 485.5 498 510.5
7.5
(25) (35)
L
5.5
5.2512.5
(Pitch)
1.25
Ø 4.5
for body mounting
101 110
86
38
36.2
18.1
85
1.2
4.5
CN4 I/O connector
CN1 Power supply connector
CN3 Encoder connector
CN2 Motor connector
SL
110
127.3 (When locking DIN rail)
133.2 (When removing DIN rail)
86
38
36.285
(11.5)
24.235
3
