SMC Networks SMCGS24C-Smart User Manual

4-1
C HAPTER 4
M AKING N ETWORK
C ONNECTIONS
Connecting Network Devices
The EZ Switch 10/100/1000 units are designed to interconnect multiple
segments (or collision domains). It can be connected to network cards in
PCs and servers, as well as to hubs, switches or routers. It may also be
connected to devices using optional SFP transceivers.
Twisted-Pair Devices
Each device requires an unshielded twisted-pair (UTP) cable with RJ-45
connectors at both ends. Use Category 5, 5e or 6 cable for 1000BASE-T
connections, Category 5 or better for 100BASE-TX connections, and
Category 3 or better for 10BASE-T connections.
Cabling Guidelines
The RJ-45 ports on the switch support automatic MDI/MDI-X pinout
configuration, so you can use standard straight-through twisted-pair cables
to connect to any other network device (PCs, servers, switches, routers, or
hubs).
See Appendix B “Cables” for further information on cabling.
Caution: Do not plug a phone jack connector into an RJ-45
port. This will damage the switch. Use only twisted-pair cables
with RJ-45 connectors that conform to FCC standards.

SMC Networks SMCGS24C-Smart Specifications

General

Ports	24
Layer	Layer 2
Switching Capacity	48 Gbps
MAC Address Table	8K
Forwarding Rate	35.7 Mpps
Jumbo Frame Support	Yes
Packet Buffer Memory	512 KB
Operating Humidity	10% to 90% (non-condensing)
Storage Humidity	5% to 90% (non-condensing)
Power Consumption	20W
Jumbo Frame Size	9216 Bytes
Management	Web-based management
Features	QoS, VLAN, IGMP Snooping, Port Mirroring
Storage Temperature	-40°C to 70°C
