H
OME
N
ETWORK
S
ETTINGS
31
• Enable to input MAC address manually (Default: Disable) - Up
to 4 WDS links can be set by specifying their wireless MAC
addresses in the AP MAC Address Table.
Parameter Description
SSID The Service Set ID (SSID) is the name of your wireless
network. The SSID must be the same on the Wireless AP and
all of its wireless clients.
Channel This device supports the following modes 11g only, 11b only,
11b/g mixed mode, Super G-Dynamic Turbo and
Super G-Static Turbo.
MAC Address The media access control address (MAC address) is a unique
identifier attached to each wireless base station.
Security Displays the security mechanism in use.
Enable WDS Enables the WDS feature. When enabled, up to 4 WDS links
can be set by clicking on the check box. Make sure the same
channel is in use on all devices. (Default: Disable)
