SMC Networks ZSE20A

-47-
No.PS※※-OMU0003-C
During an error output or when the output setting is off, the pressure value meter at the atmospheric
pressure is displayed according to the table below.
Rated range
Display at atmospheric pressure
Vacuum pressure
Compound pressure
Positive pressure
•Character string display
The Character string display function will display the specified characters on the sub display (right).
Character setting is performed using the function [F82] Input of line name.
•Display OFF
The Sub display is not displayed.
