■[F98] Output check
Correct operation of the switch output can be confirmed.
The output can be turned ON/OFF manually.
<Operation>
Press the or button in function selection mode to display [F98].
Press the button. Move on to output check.
[n] (Normal
output) is
selected
Press the
button
to set.
Return to
function
selection mode.
[F] (Forced output) is selected
Press the button to set.
Move on to OUT1 output check.
Press the button.
Move on to OUT2 output check.
Output check
Press the or button to select output check.
OUT1 output check
Press the or button to select OUT1
output check.
