■[F96] Input signal check
Checks the input status of the FUNC terminal when the auto-shift input is set.
<Operation>
Press the or button in function selection mode to display [F96].
Without input signal
With input signal
There is no corresponding function
Press the or button.
Return to function selection
mode.
Press the button for 2
second or longer.
[F96] Setting of input signal check completed Measurement mode
Input signal check
Displays the current input status on the sub screen.
