SMC Networks ZSE20B-L User Manual

-25-
No.PS※※-OMV0006-D
The Pressure switch turns on within a set pressure range (from P1L to P1H) during window comparator
mode. Set P1L, the lower limit of the switch operation, and P1H, the upper limit of the switch operation and
WH1 (hysteresis) following the instructions given on page 24.
(When reversed output is selected, the sub display (left) shows [n1L] and [n1H].)
Please refer to the "List of output modes" on page 34 for the relationship between the set values and
operation.
∗: Set OUT2 in the same way. (OUT2 output available in the IO-Link communication process data)
Setting of the normal/reverse output switching and hysteresis/window comparator mode switching are performed
with the function selection mode [F 1] Setting of OUT1 or [F 2] Setting of OUT2.
