SMC Networks ZSE20B-L User Manual

-48-
No.PS※※-OMV0006-D
■[F14] Zero cut-off setting
When the pressure display value is close to zero, the product rounds the value and zero will be displayed.
The zero cut-off range is 0.0 to 10.0% F.S., and can be set in 1.0% F.S. increments.
<Operation>
Press the
or button in function selection mode to display [F14].
Press the
button. Move on to select zero cut-off setting.
∗: The display above is an example of when [MPa] is selected for the ISE70 (1 MPa range) with the unit switching function.
∗: When the actual pressure is smaller than the displayed value in the upper line, zero will be displayed.
Example:
1 MPa range P_1 = 0.015 [MPa], H_1 = 0.01 [MPa], zero cut-off 1.0%
Press the
button to set. Return to function selection mode.
[F14] Zero cut-off setting completed
Select zero cut-off setting
Press the or button to select the value of zero cut-off.
