SMC Networks ZSE20B-L User Manual

-29-
No.PS※※-OMV0006-D
●[F 1] Setting of OUT1 Page 32
Item
Explanation
Default setting
Output mode
Either hysteresis mode, window comparator mode, error output or
output off can be selected.
Hysteresis mode
Reversed output
Selects which type of switch output is used, normal or reversed.
Normal output
Pressure setting Sets the ON and OFF point of the switch output.
ISE20B : 0.500 MPa
ZSE20B : -50.0 kPa
ZSE20BF : 50.0 kPa
Hysteresis
Appropriate setting of the hysteresis will prevent the switch output
from chattering.
ISE20B : 0.050 MPa
ZSE20B : 5.0 kPa
ZSE20BF : 5.0 kPa
Delay time Delay time of the switch output can be selected. 1.5 ms or less
Display color Selects the output according to the display color.
OUT1 ON
: Green
OUT1 OFF: Red
●[F 2] Setting of OUT2
Page 35
Same setting as [F 1] OUT1.
●Other parameter settings
Item
Page
Default setting
[F 3] Digital filter setting
Page 37
0.00 s
[F 4] Auto-preset function Page 38 Not used
[F 6] Fine adjustment of display value
Page 40
0%
[F10] Sub display setting
Page 41
std (Standard)
[F11] Display resolution setting
Page 47
1000-split
[F14] Zero cut-off setting
Page 48
0.0
[F80] Power saving mode
Page 49
OFF
[F81] Security code
Page 50
OFF
[F90] Setting of all functions Page 52 OFF
[F96] Number of pressurizing errors
Page 54
-
[F98] Output check
Page 55
N/A (normal output)
[F99] Reset to default settings Page 57 OFF
