-74-
No.PS※※-OMV0006-D
●Product individual parameters (continued)
Index
(dec)
Sub
index
Access
∗1
Parameter
Data
storage
∗2
Date
type
∗3
Initial value
(dec)
Remarks
0x071C
(1820)
0 R/W
Lower level screen
Line name
1st letter
Y U8 0
Refer to Figure "1st letter (11seg)
of Line name communication data".
0x071D
(1821)
0 R/W
Line name
2nd letter
Y U8 0
Refer to Figure "2nd to 4th letter
(7seg) of Line name
communication data".
0x071E
(1822)
0 R/W
Line name
3rd letter
Y U8 0
0x071F
(1823)
0 R/W
Line name
4th letter
Y U8 0
0x0720
(1824)
0 R/W
Line name
Left side bot
Y U8 0
0: OFF (dot OFF)
1: ON (dot ON)
0x0721
(1825)
0 R/W
Line name
Center bot
Y U8 0
0x0722
(1826)
0 R/W
Line name
Right side bot
Y U8 0
0x0456
(1110)
0 R/W
drE
(Selection of
display value
resolution)
Y U8
0x00
(0)
Setting of display value resolution
0: Normal resolution
1: Lower resolution (1/10)
0x0474
(1140)
0 R/W
Cut
(Zero-cut)
Y U8 0
Display value around 0 is displayed
as 0.
Setting range
0 ~ 10 1.0% increments
0x0708
(1800)
0 R/W
ECo
(Economy
mode)
Y U8
0x00
(0)
Setting of power saving mode
0: oFF
1: on
0x0712
(1810)
0 R/W
Pin
(use or unused
of the security
code)
Y U8
0x00
(0)
Setting of use or unused of the
security code
0: Unused
1: Used
0x0713
(1811)
0 R/W
PinCode
(Security code)
Y U16
0x0000
(0)
Setting of security code
0 ~ 999
0x07D0
(2000)
0 R
Measurement related
Process data
Conversion
formula
Inclination a
N F32
Refer to table "Inclination and
intercept to the unit specification".
(Page 65)
0x07D1
(2001)
0 R
Process data
Conversion
formula
Intercept b
N F32
0x07D2
(2002)
0 R
Peak value
N U16 0
Refer to process data on page 63
to 65.
0x07D3
(2003)
0 R
Bottom value
N U16 0
