Technical data
Control panel
Standard Designed to EN54-2 : 1997
Approval LPCB approved
Panel dimensions
in mm
height 419 x width 347 x
depth 85.5
Panel weight approximately
3.12Kg without batteries
8.2Kg with batteries
2 - 12V 7Ah batteries are
required (each battery weighing
2.54Kg [5.6lbs])
Storage
temperature
-10ºC to 55ºC
Operating
temperature
-5ºC to 40ºC
Relative Humidity
(Non condensing)
Temperature
5ºC to 45°C
up to 93%
Emission BS EN 61000-6-3:2007
Residential, Commercial & Light
Industry Class B limits
Immunity BS EN 50130-4: 1996: Part 4
Alarm systems: Electromagnetic
compatibility
Product family standard:
Immunity requirements for
components of fire, intruder and
social alarm systems
Ingress Protection IP30
Colour Door: Grey RAL 7040
HMI: Dusty Grey RAL7037
Backbox: Black
Devices per loop A maximum of up to
127 addressable devices on the
loop
Device labels Each device can be given a
32 character label for loop
device location
Relays
Fire
Fault
Voltage-free contacts
rated 1A @ 24Vdc
1 - set of change over contacts
that are configured to operate
immediately on a Fire event. The
relay is normally de-energised
1 - set of change over contacts
configured to operate
immediately on occurrence of a
Fault event. The relay is
normally energised
Master alarm
circuits and
fuses
2 - Master alarm circuits
operating at 24 volt nominal,
200 mA maximum per circuit
MA1 - Fuse FS2 250mA AS
MA2 - Fuse FS3 250mA AS
Both fuses are Ceramic type
20mm x 5mm in size and are
located on the MCB
Evacuate Input A closed input will trigger all
alarms to sound evacuate signal
to include master alarms and
activation of fire output
Class Change
input
A closed input will trigger all
configured sectors to sound the
class change signal.
RS485 Port
RS232 Port
USB Port
RS485 - (PP3) Repeat indicator
panel
RS232 - (PP10) Printer
USB - (P2) Commissioning tool
24V supply Maximum output current of
200mA is protected by a
Ceramic Fuse FS1 0.25A AS
20mm x 5mm in size, located on
the MCB.
Power taken from this supply will
affect the battery standby
duration.
Indicators Fire (red)
Power (green)
Fault 'Common' (amber)
16 - Zones (red)
Verify (amber)
Disablement (amber)
System fault (amber)
Power fault (amber)
Sounder Fault (amber)
Test (amber)
Delay (amber)
Sounder Disablement (amber)
Display Alpha-numeric display -
8 lines by 40 characters per line,
back-lit, (LCD having black
characters on green
background)
Internal sounder Audible announcement of Fire
and Fault events.
Controls at
Access level 1
Menu navigation buttons to view
events and for PIN code entry to
other access levels.
Installation instructions
12
