On completion of panel installation
On completion of all cable installation ensure the wires are neatly stored in the space above the electronics
module.
Fit the 'outer cover' by hooking it over the top edge
j of the 'backbox' and then close the bottom of the
'outer cover'
k onto the 'backbox' and secure the cover by the captive screws using the allen key.
"
All the remaining parts must be kept in a safe and secure place for the servicing
organisation to fit during commissioning of the system.
