Panel installation
Panel installation
A SENTRI4 panel include the following parts:
Back box assembly with PSU to power the Control panel
Inner door
Moulded outer door
Loop Card (1- loop card supplied), can accommodate up to 4 maximum
Main Controller Card
SENTRI4 is supplied with 2x12V 21Ah batteries
Parts supplied in spares packs:
Part Qty - SENTRI4
Cable tie
3
Ferrite core
1
22K 0.5W Resistor
2
Battery lead
1
Spade tag
2
Link lead
1
i
Instructions
1
20 x 5mm Fuse 6.3A QB Ceramic
1
20 x 5mm Fuse 3.15A AS Ceramic
1
20 x 5mm Fuse 3.15A AS Glass
1
Adhesive backed foam pad
1
Each battery pair of 2 x 12V 21Ah is supplied with:
4 x bolts
4 x spring washers
4 x washers
