How to minimise cross talk
Domain Bridge across Networks
It is possible to connect two or more SENTRI networks together by means of domain
bridge. To domain bridge two or more networks a Domain bridge IO card must be
installed in the bridging node / panel.
There are various methods of domain bridging depending on the distances between
node / panel. Domain bridge can be made directly using RS232 ports of the IO card,
via modem or Fibre optics.
Methods of domain bridging
A domain bridge IO card is required to be installed in the bridging panel/node.
RS232
15m max
Domain bridge IOC
DOMAIN
BRIDGE
SenTRI 4 Fire System
