SMS SenTRI2 - Networking and Sensors; Copper Network Connectivity

31
SenTRI4 fire system
Copper Network
It is possible to network together up to 31 SenTRI Control panels, each tted with
a network card for network connections. The Network card permits communication
between other control panels. The cable distance between panels and nodes can be
up to 1.2Km maximum. A network controller which is the Control panel with the lowest
address is a central point for information about the networked system.
Control panel
Control panel
Control panel Control panel Control panel
#
#
# - 1.2Km Copper network cable distance
#
#
#
#
Control panel
