SMS SenTRI2 - RS232 Domain Bridge Using Domain IO Card; On Completion of Wiring Installation

35
SenTRI4 fire system
RS232 Domain bridge using Domain IO card
SenTRI 4 Fire System
Designed to EN54 Pt 2 & 4
Healthy
15:45
Fault
System Fault
Test
Fire
Power
Power Fault
Disablement
Sounder
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
17 18 19 20 21 22 23 24 25 26 27 28 29 30 30 32
Zones
Previous
Next
Delay
Verify
EN54 Parts 2 & 4
f o u r
0XXXX
SenTRI 4 Fire System
Designed to EN54 Pt 2 & 4
Healthy
15:45
Fault
System Fault
Test
Fire
Power
Power Fault
Disablement
Sounder
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
17 18 19 20 21 22 23 24 25 26 27 28 29 30 30 32
Zones
Previous
Next
Delay
Verify
EN54 Parts 2 & 4
f o u r
0XXXX
DOMAIN
BRIDGE
Control panel
IOCIOC
Domain 1
Domain 2
RS232 15m Cable length
Backplane Backplane
Control panel
PB2
N/C 0V CTS RX RTS TX
DOM IO CARD IN SLOT P7
PB2
N/C 0V CTS RX RTS TX
DOM IO CARD IN SLOT P7
On completion of wiring installation
On completion of all wiring ret the temporary cover onto the back box. All outstanding
work is done by the servicing organisation during commissioning.
