When length of an offset (or sum of head minus offset for interchangeable head) is negative, maximum fastener
target is limited by following formulas:
240 in-lb wrench:
Maximum Target Torque = offset * 24 + 240
100 ft-lb wrench:
Maximum Target Torque = offset * 7 + 100
Offset
Max Target
Offset
Max Target
-1"
216 in-lb
-1"
93 ft-lb
-2"
192 in-lb
-2"
86 ft-lb
-3"
168 in-lb
-3"
79 ft-lb
-4"
144 in-lb
-4"
72 ft-lb
250 ft-lb wrench:
Maximum Target Torque = offset * 11 + 250
250L ft-lb wrench:
Maximum Target Torque = offset * 8 + 250
Offset
Max Target
Offset
Max Target
-1"
239 ft-lb
-1"
242 ft-lb
-2"
228 ft-lb
-2"
234 ft-lb
-3"
217 ft-lb
-3"
226 ft-lb
-4"
206 ft-lb
-4"
218 ft-lb
600 ft-lb wrench:
Maximum Target Torque = offset * 14 + 600
Offset
Max Target
-1"
586 ft-lb
-2"
572 ft-lb
-3"
558 ft-lb
-4"
544 ft-lb
Note: When using a negative offset, entering a target torque greater than maximum values above may cause an overtorque error
before reaching fastener target torque and possibly damage wrench.
Viewing Stored Torque and Angle Data
Torque data is stored in memory after each torque cycle if applied torque has reached target value. Torque and
angle data is stored in memory after each angle cycle if applied angle has reached target value. Memory
Indicator is displayed when data is stored in non-volatile memory.
1. To view stored torque and angle data, the CTECH will only store data while the controller is either out of
range or turned off.
2. Highlight SHOW DATA menu selection by pressing UP/DOWN buttons then press ENTER button to display
Show Data screen.
3. In Show Data screen, scroll through each stored data record by pressing UP/DOWN buttons.
Example: 0002 = Show Data List Counter: TQ = Peak torque value
0001 = Show Data List Counter: TQ = Peak torque value: ANG = Peak angle value
4. Pressing ENTER button while on Show Data screen returns to main menu.
00
M 100.0
FT-LB
0002: 15:40:15
2012/09/26
TQ: 100.2 FT-LBS
M
EXIT
LANGUAGE
SET HEAD LENGTH
M SHOW DATA
UP/DOWN buttons
0001: 15:35:05
2012/09/26
TQ: 100.3 FT-LBS
M ANG: 84°
EXIT
LANGUAGE
SET HEAD LENGTH
M SHOW DATA
ENTER
button
held
Target Screen
ENTER
button
UP/DOWN buttons
