Snap-On ControlTech CTLNK1R240 User Manual

Auto Backlight Setup
This function will allow user to enable or disable backlight from turning on during torque or angle measurement.
1. From Settings menu, use UP/DOWN buttons to highlight AUTO BACKLIGHT selection then press ENTER
button.
2. AUTO BACKLIGHT screen is displayed.
3. Use UP/DOWN buttons to highlight ENABLE (factory default) or DISABLE selection.
4. Press ENTER button to accept selection and exit to Settings menu.
Toggle Backlight Setup
This function will allow user to enable or disable backlight toggle function. If toggle mode is disabled, BACKLIGHT
button turns on backlight and it automatically turns off after five seconds following any last button press. If
toggle mode is enabled, a BACKLIGHT button press will turn on backlight and it will remain on until next
BACKLIGHT button press.
1. From Settings menu, use UP/DOWN buttons to highlight TOGGLE BACKLGHT selection then press ENTER
button.
2. TOGGLE BACKLGHT screen is displayed.
3. Use UP/DOWN buttons to highlight ENABLE or DISABLE (factory default) selection.
4. Press ENTER button to accept selection and exit to Settings menu.
Note: Backlight will turn off when wrench powers down either by POWER button press or sleep
time.Note: If toggle backlight is enabled and backlight is on, backlight will remain on
during and after applying torque.
EXIT
SHOW INFO
SLEEP TIME
LCD CONTRAST
UP/DOWN buttons
ENTER
button
AUTO BACKLIGHT
ENABLE
DISABLE
SLEEP TIME
LCD CONTRAST
KEY BEEP
AUTO BACKLIGHT
ENTER
button
UP/DOWN buttons
AUTO BACKLIGHT
ENABLE
DISABLE
EXIT
SHOW INFO
SLEEP TIME
LCD CONTRAST
UP/DOWN buttons
ENTER
button
TOGGLE BACKLGHT
ENABLE
DISABLE
LCD CONTRAST
KEY BEEP
AUTO BACKLIGHT
TOGGLE BACKLGHT
ENTER
button
UP/DOWN buttons
TOGGLE BACKLGHT
ENABLE
DISABLE
