81
M2 Data Acquisition Device Digital Multimeter Operations
1— Mode
2— Scale
3— Timebase
Figure 8-12 Sample display screen
Trigger Selections
Triggering allows you to set the scope so that it begins sampling and displaying a trace once
predetermined signal conditions, or triggers, are met. Triggering produces a much more stable
waveform. The trace always begins at the trigger point, so the image does not appear to flicker or
drift as it updates.
1— Mode
2— Trigger channel
3— Trigger slope
4— Trigger level
Figure 8-13 Sample trigger screen
' ' ' '
'SFF[F
%JTQMBZ 5JNF4DBMF

&+
'&
P6
7$872
7&+
9
9'LY
7

' ' ' '
4MPQF
5SJHHFS $IBOOFM-FWFM

&+
'&
P6
7$872
7&+
9
9'LY
7

