Snorkel S3246E - Wire Harness, Internal - Upper Control Box

S2646/S3246 Electrical – 39
Wire Harness, Internal – Upper Control Box
Item Part No. Qty. Description
0361227 C
0361227 1 WIRE HARNESS
1 3049862 1 RECEPT
2 3040341 12 PIN CONTACT SIZE 16 16/18 GA
3 3040097 2 SEALING PLUG -16 DEUTSCH
4 3049993 1 CONN AMP 12-PIN PLUG
5 3049985 8 AMP PIN CONTACT 20/14 GA
6 3044142 7 TERM R6I 22/18
7 3049994 2 TERM SPADE6I 22/16 GA
8 960359 1 TERM SPADE6I 18-14GA
12 3040046 1 TERM MALE250FI 18/22
