Snorkel S3246E - Chassis Wiring

S2646/S3246 Electrical – 3
Chassis Wiring
104
105
See Detail A
Item Part No. Qty. Description
104 0371896 1 WIRE 2 R375 R313 149 BLK
105 0151157 1 WIRE 2 R375 R313 142 RED
AW0371887 B
Detail A
7A
3V
3X
7
3J
MAIN HARNESS
POTHOLE
STACK
ATTACH TO GROUND STUD
TO HYDRAULIC
TRAY
TO LIFT
CYLINDER
TO LEVEL SENSOR
