S2646/S3246
Electrical –
5
Limit Switch
Item
Part No.
Qty
.
Description
3028795 D
3028795
1
SWITCH
ASSEMBL
Y
1
3028796
1
SWITCH, LIMIT
2
3040341
4
PIN
CONT
ACT
SIZE 16 16/18 GA
3
3049889
1
CONNECTOR 4-PIN
4
3049891
1
LOCK WEDGE 4-PIN
88
90
