Snorkel S3246E - Cylinder, Steering

S2646/S3246 Hydraulics – 5
6047108 1 CYLINDER, STEER – GREEN
8071008 1 SEAL KIT, CYLINDER – GREEN (includes items 10 through 15)
1 6091511 1 HEAD, CYL
2 8070306 1 LOCK WIRE
3 8070871 1 O-RING
4 8071014 1 LOCKNUT
5 8071015 1 PISTON
6 8071016 1 WASHER
7 8071017 1 ROD ASSY
8 8071018 1 BARREL ASSY
9 8071019 1 BACKUP
10 Kit item 2 BACKUP 28-806P-1
11 Kit item 2 O-RING 27-806-0
12 Kit item 1 O-RING 27-819-0
13 Kit item 1 BACKUP 28-806-1
14 Kit item 1 ROD WIPER 30-963
15 Kit item 1 ROD SEAL 29-1035-UR
Cylinder, Steering
Item Part No. Qty. Description
AW6047108
10
456
11
78
1
12
23
9
11
13
14
15
