S2646/S3246 Repair Parts – 29
Step Installation
AW0410052
1 300778 4 NUT HEX .500-13
4 0371884 1 WELDMENT STEP 2646
0371780 1 WELDMENT STEP 3246
5 0410056 1 WLDMT, LADDER 2646 – CE (optional for all other units)
0372013 1 WLDMT, LADDER 3246 – CE (optional for all other units)
11 970909 4 BLT .500-13 1.50 GR5
13 986359 8 WSHR FLAT .500
Item Part No. Qty. Description
