S2646/S3246
Hydraulics –
19
Hydraulic Hoses, Scissor St
ack – S2646
0410052 B
Item
Part
No.
Q
ty
.
Description
10
1
5036905
1
FTG ELB45SWVL-6S-6S STL
10
2
5035305
1
FTG ELB90STRTHD-6B-6S STL
20
2
0240770
1
HOSE-6-6S-6S 168
76
78
