S2646/S3246 Repair Parts – 13
1 300437 2 BEARING FLANGED
2 300492 1 LATCH LH TRAY ROTARY LOCK
3 300765 1 SCREW THUMB .25-20 X 1.00 TYPE B
4 301440 1 RETURN OIL FILTER
5 0371862 1 WLDMT HYDRAULIC TRAY
6 0371866 1 HYDRAULIC TANK
9940021 1 TANK FILLER CAP (included with item 6)
7 0371868 1 TUBE ASSY TANK RETURN
8 0410064 1 LOWER CONT BOX
9 554316 1 BREATHER 40 MICRON 1/4" NPT
10 970029 4 BLT HEXHD .250-20 .75 GR5
11 970049 7 BLT HEXHD .250-20 1.00 GR5
12 970279 2 BLT .313-18 1.50 GR5
13 970469 7 BLT HEXHD .375-16 1.00 GR5 PLATED
14 970849 3 BLT. 500-13 1.25 GR5
15 978239 2 BLT. .375-24 .75
16 984329 2 NUT JAM .250-20
17 986019 9 WASHER FLAT .250
18 986269 4 WASHER FLAT .313
19 986299 3 WASHER FLAT .375
20 987099 2 WASHER LOCK .250
21 987119 3 WASHER LOCK .375
22 3087787 1 CONTACTOR, 24V SEALED
23 3087789 1 CONTROLLER, MOTOR 24V 360A
24 3087790 1 MOTOR 24V PUMP MOUNT
25 5035306 2 FTG ELB90STRTHD-8B-8S STL
26 5035322 1 FTG ELB90STRTHD-8B-10S STL
27 5035706 1 FTG ELB45STRTHD-8B-8S STL
28 5036703 1 FTG TEE SWVL RUN-4S-4S STL
29 5037003 3 FTG ELB90SWVL-4S-4S STL
30 5037005 1 FTG ELB90SWVL-6S-6S STL
31 5037006 4 FTG ELB90SWVL-8S-8S STL
32 5037007 1 FTG ELB90SWVL-10S-10S STL
33 5063905 1 FTG NUT-6S STL PARKER 6BTX-S
34 5064001 1 FTG RDCR TUBE END-6S-4S
35 5065705 3 FTG ADPTR STRTHD-6B-4S
36 5065708 1 FTG ADPTR STRTHD-8B-6S STL
37 5065709 4 FTG ADPTR STRTHD-8B-8S STL
38 5065711 2 FTG ADPTR STRTHD-12B-8S STL
39 5065712 1 FTG ADPTR STRTHD-10B-10S STL
40 5065805 1 FTG ADPTR STRTHD-LG -6B-6S STL
41 5070005 1 NIPPLE DIAGNOSTIC -4JIC FEM
42 5070006 2 NIPPLE DIAGNOSTIC -4 O-RING
43 5075305 1 FTG PL HOL HEX-6B STL
44 5080042 1 STRAINER SUCTION
45 5560004 9 NUT LKG .250-20-ESNA
46 5560031 3 NUT LKG .313-18 ESNA
47 5560033 4 NUT LKG .375-16-ESNA
48 6019056 1 VALVE, MAIN MANIFOLD
49 6029637 1 PUMP 2 SEC 6CC/4CC
101 0410065 1 LOWER CONT BOX (CE only)
Hydraulic Tray
Item Part No. Qty. Description
To Next Page
