Repair Parts – 16B S2646/S3246
0372252 1 ASSY, SCISSOR STACK S2646E
1 0372233 1 WLDMT 1ST INNER ARM 2646
2 0372234 1 WLDMT 2ND INNER ARM 2635-3246
3 0372235 1 WLDMT 3RD INNER ARM 2646
4 0372236 1 WLDMT 4TH INNER ARM 2646
5 0372241 2 WLDMT OUTER ARM 5mm WALL
6 0372242 2 WLDMT OUTER ARM 6mmWALL
7 0372250 2 WLDMT OUTER ARM 4mm WALL
8 0372244 2 WLDMT OUTER ARM 6mm WALL
9 2509726 40 BEARING, CSB, CRG-4553-30
10 2509671 16 BRG 1.75ID 1.94OD 1.50
11 0372248 20 PIN 45mm OD X 8.625[219.1mm] LG
12 5563371 20 WSHR CUSTOM 65mmOD X 45.75mm ID X 12GA
13 5592003 20 SNAP RING 45MM EXT
14 056058-080 20 HHCS M8 x 1.25 x 80 G8.8 ISO 4014_DIN 931
15 0372016 1 POTHOLE ACTUATOR WLDT 3246
16 0410016 2 ASSY PIN BOTTOM SLIDE
17 0371904 2 SAFETY PROP
18 1370417 2 SCISSOR ARM MOUNT
19 0410032 4 ASSY PIN TOP SLIDE
20 1370412 2 PLATFORM SLIDE ASSY
21 1370418 1 PIN LOWER
22 1370411 2 LOWER SLIDE BLOCK
23 058493-025 3 M10 X 25MM HEX HEAD
24 056066-010 3 NUT, LOCK, NYLON, M10, DIN985, GR8
25 056064-012 4 NUT, NYLOCKNUT DIN985 M12 10.0
26 510561-012 4 WASHER M12 FLAT DIN 125 SS
27 510581-030 4 BLT HEXHD M12-1.75 30MM
28 0410045 2 PIN, 1.25 X 7.931 GRIP, PLATED
29 056066-008 22 NUT, NYLOCKNUT DIN985 M8 8.0 Z
30 065059-065 2 HHCS M8 x 1.25 x 65 G8.8 ISO 4014_DIN 931
31 056021-006 6 M6 SPRING WASHER
32 058491-016 6 BOLT, HEXSETSCREW DIN933 M6 X
33 056021-008 8 Washer SpringWasher DIN127B M8 ZincPlated
34 056059-020 8 M8 X 20MM HEX HEAD B
35 6047107-3 1 CYL 3.50 41.63 LIFT
Not Shown
06018023 1 SOLENOID VALVE W/ MANUAL SV10-22J-O-N-24DS
06091348 1 CHECK VALVE POPPET FLOW WITH 0.045" ORIFICE
5090048 8 ft HOSE GUARD-16
0410048 1 CABLE, EMER BLEED DOWN S3246
Scissor Stack – S2646E
Item Part No. Qty. Description
