Repair Parts – 18 S2646/S3246
0371500 1 ASSY, SCISSOR STACK S3246
1 0361130 2 WLDMT PIVOT ARM
2 0361477 3 SCISSOR ARM WEAR PAD
3 0371510 4 PIN CYLINDER MNT SL32E
4 0371836 2 WLDMT EMER BLEED DOWN
5 0371845 26 PIN 1.750OD 8.63 LONG
6 0371846 1 WLDMT THIRD INNER ARM
7 0371849 1 ARM INNER 2ND .188 WALL
8 0371850 1 WLDMT FIFTH INNER ARM .188WALL
9 0371897 2 ASSY, SLIDE PAD
10 0371904 2 SAFETY PROP
11 0371943 2 WLDT OUTER ARM .25 TUBE
12 0410005 1 WLDMT FIRST INNER ARM
13 0410006 1 ARM INNER 2ND .188 WALL
14 0410007 4 WLDMT OUTER ARM 0.188 TUBE
15 0410016 2 ASSY PIN BOTTOM SLIDE
16 0410019 2 WLDMT SLIDE BRKT
17 0410021 2 WLDMT PLATF BRKT MT
18 0410027 3 WLDMT OUTER ARM .125WALL
19 0410029 1 PIPE CONNECTOR SCISSOR ARM
20 0410032 4 ASSY PIN TOP SLIDE
21 0410049 1 WLDMT, OUTER ARM W/BAR
22 970009 4 BLT HEXHD .250-20 .500 GR5
23 970019 6 BLT HEXHD .250-20 .625 GR5
24 970469 3 BLT HEXHD .375-16 1.00 GR5
25 970529 6 BLT HEXHD .375-16 2.50 GR5
26 970569 26 BLT HEXHD .375-16 3.50 GR5
27 986009 2 WASHER FLAT 10
28 987099 10 WASHER LOCK .250
29 2509671 68 BEARING 1.75ID 1.94OD 1.50LG
30 5560031 2 NUT LKG .313-18 ESNA
31 5560033 35 NUT LKG .375-16 ESNA
32 5560038 2 NUT LKG 10-32 ESNA
33 5569853 26 BSHG MCHRY 1.75ID 2.50OD 14GA
34 5569994 2 BLT SHLDR .375X2.0 .3125-18X.5
35 5590175 26 SNAP RING 1.75 ID HEAVY DUTY
36 6047075 2 CYLINDER, LIFT
103 5090048 8 ft HOSE GUARD-16
104 0410048 1 CABLE, EMER BLEED DOWN S3246
Scissor Stack – S3246
Item Part No. Qty. Description
To Next Page
