Repair Parts – 18B S2646/S3246
0372251 1 ASSY, SCISSOR STACK S3246E
1 0372237 1 WLDMT IST INNER ARM 3246
2 0372234 1 WLDMT 2ND INNER ARM 2635-3246
3 0372238 1 WLDMT 3RD INNER ARM 3246
4 0372239 1 WLDMT 4TH INNER ARM 3246
5 0372240 1 WLDMT 5TH INNER ARM 3246
6 0372250 1 WLDMT OUTER ARM 4mm WALL
7 0372245 2 WLDMT OUTER ARM 4mm WALL
8 0372246 1 WLDMT OUTER ARM 4mmWALL
9 0372242 2 WLDMT OUTER ARM 6mmWALL
10 0372247 2 WLDMT OUTER ARM 5mm WALL
11 0372241 2 WLDMT OUTER ARM 5mm WALL
12 1370412 2 PLATFORM SLIDE ASSY
13 1370417 2 SCISSOR ARM MOUNT
14 2509726 52 BEARING, CSB, CRG-4553-30
15 0372248 26 PIN 45mm OD X 8.625[219.1mm] LG
16 5563371 26 WSHR CUSTOM 65mmOD X 45.75mm ID X 12GA
17 5592003 26 SNAP RING 45MM EXT
18 2509671 16 BRG 1.75ID 1.94OD 1.50
19 0410032 4 ASSY PIN TOP SLIDE
20 1370411 2 LOWER SLIDE BLOCK
21 1370418 1 PIN LOWER
22 0410016 2 ASSY PIN BOTTOM SLIDE
23 0371510 4 PIN, 1.25 X 7.057 GRIP
24 6047075 2 CYLINDER, LIFT SL3246
25 0372016 1 POTHOLE ACTUATOR WLDT 3246
26 0371904 2 SAFETY PROP
27 056058-080 26 HHCS M8 x 1.25 x 80 G8.8 ISO 4014_DIN 931
28 056066-008 30 NUT, NYLOCKNUT DIN985 M8 8.0 Z
29 510561-012 4 WASHER M12 FLAT DIN 125 SS
30 056064-012 4 NUT, NYLOCKNUT DIN985 M12 10.0
31 056066-010 3 NUT, LOCK, NYLON, M10, DIN985, GR8
32 058493-025 3 M10 X 25MM HEX HEAD
33 510581-030 4 BLT HEXHD M12-1.75 30MM
34 065059-065 4 HHCS M8 x 1.25 x 65 G8.8 ISO 4014_DIN 931
35 056021-006 6 M6 SPRING WASHER
36 058491-016 6 BOLT, HEXSETSCREW DIN933 M6 X
37 056021-008 8 Washer SpringWasher DIN127B M8 ZincPlated
38 056059-020 8 M8 X 20MM HEX HEAD B
Not Shown
6047075 2 CYLINDER, LIFT
5090048 8 ft HOSE GUARD-16
0410048 1 CABLE, EMER BLEED DOWN S3246
Scissor Stack – S3246E
Item Part No. Qty. Description
